C1000S

Expandable

Can be paralleled up to 30MW of power

Tradicionalni izvori energije postaju sve nepouzdaniji i skuplji. U međuvremenu, dok vlade i agencije stvaraju pritisak širom sveta da smanje globalne emisije, kupci širom sveta očekuju da se preduzeća prilagode održivijim praksama.

SPECIFICATION

Rating: 1,000 kW

Electrical Efficiency LHV: 33%

Combined Heat And Power Efficiency: Up to 90%

Voltage: 400-480 VAC

Frequency: 50/60 Hz, Grid Connect<br>10-60 Hz, Stand Alone

Electrical Service: 3-Phase, 4-Wire Wye

Width: 3.0 m (117 in)

Depth: 9.1 m (360 in)

Height: 2.9 m (114 in)

Weight: Grid Connect – 17,100 kg (37,700 lbs); Dual Mode – 20,650 kg (45,500 lbs)

Net Heat Rate LHV: 10.9 MJ/kWh (10,300 BTU/kWh)

Exhaust Temperature: 280 ºC (535ºF)

Exhaust Gas Flow: 6.7 kg/s (14.7 lbm/s)

Compatible Fuels: Natural Gas, Liquid Fuels (Ultra Low Sulfur Diesel #2), Biogas (Landfill, Digester), Associated Gas, Sour Gas, LPG

NOTES

Nominal full power performance at ISO conditions: 59˚F, 14.696 psia, 60% RH
Height dimensions are to the roofline. Exhaust outlet can extend up to 7 inches above the roofline.
Specifications based on high pressure natural gas systems. Values may vary with other fuel types.
